Name: Santa Cruz Blur GX AXS
SKU: pzrxrhvk67985
Availability: InStock

Description

We tapped into everything we’ve learned from years of making the highest quality carbon full-suspension bikes and added the super-efficient Superlight™ suspension to craft a World Cup-winning XC weapon. The Blur GX AXS might not guarantee you a race win — but being the lightest, full-suspension carbon XC bike we’ve ever built, it might just be the edge you need to finish first… or at least cross that finish line faster.

Features

C Carbon Frame built for elite racing
Superlight™ Suspension with 107mm rear and 110mm front travel
Two Water Bottle Mounts for all-day trail readiness
RockShox Sid SL Select+ Fork and SidLuxe Select+ Shock with remote lockout
SRAM GX AXS T-Type Drivetrain — flawless wireless shifting
SRAM Level Bronze Stealth 4-Piston Brakes for race-level control
Maxxis Rekon Race 29″x2.4″ Tires for speed and grip

Frame

Material: Carbon C
Travel: 107mm (Rear) / 110mm (Front)
Suspension System: Superlight™
Wheel Size: 29
Weight: 26.58 lbs / 12.06 kg

Suspension

Fork: RockShox Sid SL Select+, 110mm, w/Remote
Shock: RockShox SidLuxe Select+, 190×42.5, 3-Position, w/Remote
Remote: SRAM TwistLoc Ultimate, 3-Position, Full Sprint

Drivetrain

Bottom Bracket: SRAM DUB 73mm MTB Wide BB
Cassette: SRAM GX Eagle T-Type, 10-52t
Chain: SRAM GX Eagle T-Type, Flattop, 12spd
Chainguide: OneUp Chainguide
Crankset: SRAM GX Eagle DUB T-Type, 34t
Rear Derailleur: SRAM GX Eagle AXS T-Type, 12spd
Right Shifter: SRAM AXS Pod Bridge

Brakes

Brakes: SRAM Level Bronze Stealth 4-Piston
Front Rotor: SRAM HS2 180mm
Rear Rotor: SRAM HS2 160mm

Cockpit

Grips / Bar Tape: SRAM Grips
Handlebars: Santa Cruz Carbon Flat Bar, 31.8×760, 7mm Rise
Headset: Cane Creek 40 IS Integrated
Saddle: SDG Bel-Air V3, Lux-Alloy Atmos
Seatpost: OneUp Dropper Post, 31.6
Stem: SRAM Atmos, 60mm

Wheels & Tires

Front Rim: RaceFace ARC Offset 27 29″
Front Hub: DT Swiss 370, 15×110, 6-Bolt, 28h
Front Tire: Maxxis Rekon Race 29″x2.4″, 3C MaxxSpeed, EXO
Rear Rim: RaceFace ARC Offset 27 29″
Rear Hub: DT Swiss 370, 12×148, XD, 6-Bolt, 36t, 28h
Rear Tire: Maxxis Rekon Race 29″x2.4″, 3C MaxxSpeed, EXO

Specifications

Component	Specification
Bottom Bracket Shell	73mm Threaded
Rear Brake Mount	160 PM
Shock Length	190mm
Fork Compatibility	100–120mm
Fork Offset	44mm
Front Derailleur Mount	No compatibility
Headset	Integrated (IS41/52)
Max Chainring Size	36t
Max Tire Clearance	2.4″
Seat Clamp Diameter	36.4mm
Seat Post Diameter	31.6mm
Shock Bushing Size (Front)	20×8
Shock Bushing Size (Rear)	20×8
Shock Stroke	42.5mm (XC) / 45mm (TR)
Water Bottle Mounts	2 inside main triangle / 1 under downtube

Size Guide

Size	Rider Height	Reach
Small	5’1″ – 5’5″ (155–165 cm)	435 mm
Medium	5’5″ – 5’9″ (165–175 cm)	460 mm
Large	5’9″ – 6’1″ (175–185 cm)	480 mm
X-Large	6’0″ – 6’4″ (183–193 cm)	500 mm
